Insulated Panels for Cold Room, Freezer Room (walk in freezer) - Pretoria and Johannesburg (Gauteng, South Africa)

MANUFACTURERS OF TONGUE AND GROOVE (MALE – FEMALE) AND HARDBOARD BARRIER STRIP JOINTS FOR INSULATED PANELS.

Frigipan’s insulated panels offer a complete bespoke design for cold rooms & freezer rooms. Our insulated panels are a favourite choice for contractors in the Pretoria and Johannesburg area (Gauteng), but we also have clients from other regions in South Africa and across the border, as these panels are providing flexible solutions to suit any environment.

Range of panel widths and heights all manufactured in our factory 50 – 200mm polystyrene insulated panels for thermal efficiency.
Our panels consist of standard1200mm wide Left and Right hand corners giving you the option to move the standard panels, standard corners or standard door frame around as you like.

There is a comprehensive range of door options –  Cold & Freezer room swing doors, Personnel doors for busy preparation areas, Glass doors (Slam on & Architrave) and sliding doors which are ideal in areas where space is an issue.

Included accessories in all our cold and freezer room insulated panel packages are – Bulk head light fitting, light switch & 7w LED globe, Aluminium angle, silicone, screws, nail in anchors and thermometer.

Panels is Manufactured from Virgin Grade Expanded Polystyrene cladded with 0.5mm white ArcelorMittal Chromadek®

Frigipan’s cold room panels consist of a rigid EPS (Expanded PolyStyrene) foam core with Prepainted Frost white AZ150 Aluzinc sheets permanently bonded to both sides. A finished building, ceiling or partition wall provides a strong and reliable thermal performance system that can be installed quickly and easily by almost anyone.

Frigipan insulated panels are energy efficient and feature an aesthetic profile that will look good for years to come. From small cold rooms to large commercial buildings, demising walls, ceilings to partitions, Frigipan insulated panels provide the ideal energy efficient and economical continuous insulation solution for any building project.

Insulated Panels for Cold Rooms and Industrial Applications

Insulated panels are a crucial component in creating efficient, high-performance cold rooms and refrigeration spaces. Designed to maintain specific temperature ranges, they provide the necessary thermal barrier to ensure that perishable goods are stored safely. Whether you’re in industrial or commercial sectors, insulated panels play an essential role in maintaining the integrity of your cold storage solutions. At [Your Company Name], we specialize in installing insulated panels tailored to a variety of needs across numerous industries.

The Role of Insulated Panels in Cold Storage Solutions

Insulated panels are designed to provide superior thermal insulation, energy efficiency, and durability. Constructed from high-quality materials, these panels consist of a core of insulating material sandwiched between two protective outer layers. The panels form a tight seal that helps to prevent heat transfer, ensuring that cold rooms and refrigeration spaces maintain optimal temperatures with minimal energy consumption. This is crucial for industries that rely on precise temperature control to preserve the quality and safety of their products.

Industrial Applications

Industries such as food processing, cold storage, and refrigeration warehouses heavily rely on insulated panels to keep their operations running smoothly. The use of these panels is widespread in various industrial applications, where maintaining strict temperature control is vital.

  1. Refrigeration Warehouses
    Refrigeration warehouses are large-scale facilities where temperature regulation is key to preserving the quality of perishable goods. Insulated panels are installed to create an efficient thermal envelope, helping to reduce energy costs while maintaining the cold environment needed for long-term storage.

  2. Food Processing Facilities
    In food processing, temperature control is critical at every stage of production. Insulated panels in these facilities help maintain cold rooms where raw ingredients, semi-processed foods, and finished products are kept at ideal temperatures, preventing contamination and spoilage.

  3. Cold Storage Facilities
    Cold storage facilities require consistent, reliable refrigeration to store a variety of perishable items. Insulated panels ensure these spaces are well-sealed, providing a durable, energy-efficient solution that helps businesses meet health and safety standards.

  4. Food Distribution Centers
    Food distribution centers rely on cold storage solutions to keep goods fresh during the transportation process. By using insulated panels, these centers maintain the cold chain from the point of storage to final delivery, ensuring product quality.

  5. Ice Plants
    Ice plants produce and store ice for commercial and industrial use. Insulated panels are essential in maintaining the cold temperatures necessary to prevent the ice from melting, ensuring a consistent supply for businesses.

  6. Blast and Spiral Freezers
    Blast and spiral freezers rapidly reduce the temperature of products to preserve their freshness and nutritional value. The installation of insulated panels in these environments ensures that temperature fluctuations are minimized, allowing for quick and efficient freezing.

Commercial Applications

Beyond industrial settings, insulated panels are also highly beneficial in commercial spaces such as restaurants, supermarkets, and bakeries, where temperature control is equally important for food safety and preservation.

  1. Restaurants
    In the restaurant industry, cold rooms and freezers are essential for maintaining the freshness of ingredients. Insulated panels provide a solution for creating cold storage areas that are energy-efficient, ensuring that restaurants can safely store their inventory without excessive energy consumption.

  2. Supermarkets
    Supermarkets handle a wide variety of perishable goods, from fresh produce to frozen items. Insulated panels are used to create cold storage sections within the store, keeping products at their required temperatures while ensuring energy efficiency across large spaces.

  3. Convenience Stores
    Convenience stores use insulated panels in walk-in refrigerators and freezers to store beverages, snacks, and other perishable goods. These panels help regulate temperature and create an easy-to-maintain environment for daily operations.

  4. Bakery
    Bakeries often require cold rooms to store ingredients like butter, dairy, and other perishable items. Insulated panels provide an efficient way to create temperature-controlled environments within the bakery, helping maintain the freshness and quality of the products.

  5. Floral Shops
    Florists rely on refrigerated storage to keep flowers fresh for as long as possible. Insulated panels in floral storage areas help maintain the necessary cool temperatures, ensuring that flowers remain vibrant and healthy until they reach customers.

  6. Catering Services
    Catering businesses often require mobile or temporary cold rooms for events. Insulated panels are a flexible solution for creating portable refrigeration spaces that can be customized for different catering needs, ensuring food stays fresh and safe for consumption.

Energy Efficiency and Durability

One of the biggest advantages of using insulated panels in both industrial and commercial applications is their energy efficiency. By creating an effective thermal barrier, these panels reduce the amount of energy required to maintain cold temperatures, translating into significant cost savings over time. Additionally, insulated panels are designed to be highly durable, resistant to moisture, and easy to clean, making them ideal for environments that require stringent hygiene standards.

INSULATED PANELS PROVIDING FLEXIBLE SOLUTIONS TO SUIT ANY ENVIRONMENT

FRIGIPAN OFFERS A COMPLETE BESPOKE DESIGN

Panels are made from Virgin Grade (Fire retardant) Expanded Polystyrene (EPS) in between 0.5mm white ArcelorMittal Chromadek® with PVC protection film

Insulation
Insulated panels thickness ranges from 50 – 250mm
EPS density: 12kg/m3 , 15kg/m3 , 20kg/m3 , 24kg/m3 and 30 kg/m3

Standard panel size
Most cost effective, but all sizes can be made on request.

  • Barrier strip – 1200mm wide
  • Tongue & Groove – 1170mm wide
  • Maximum length available – 8500mm

PANEL FINISH



0.5mm Frost white ArcelorMittal Chromadek® _ Colour: Frost white. Food safe quality _ Cladded over Virgin Grade Expanded Polystyrene available in 12 , 15 , 20 , 24 and 30Dv

Additive Icon
Insulation Coils
Insulation - Polystyrene
Description
Tolerance
  • Panel length < 3m
  • Panel length > 3m < 9m
  • Panel width
  • Panel thickness
  • ± 3mm
  • ± 6mm
  • ± 2mm
  • ± 2mm
